TSCY SERIES DRUM SIEVE
time：2017-12-29 09:40:11
Feature ：
The TSCY series drum sieve are suitable for the preliminary cleaning of raw materials in the silos, rice mill, flour mill and malt plant to remove the stems, leaves, mudballs, hempropes and other large impurities. it will reduce the impurities in raw materials and increase the efficiency of next cleaning process.
Main Technical Specification：
| Model | TSCY80 | TSCY100 | TSCY125 |
|---|---|---|---|
| The size of sieve(mm) | ф800×950 | ф1000×1150 | ф1250×1400 |
| rotation speed(r/min) | 17 | 21 | 21 |
| capacity(t/h) | 20 | 35 | 50 |
| The inhale breeze measures(m3/h) | 720 | 900 | 1100 |
| shape size(mm) | 1800×1065×1390 | 2000×1260×1590 | 2250×1510×1850 |
| weight(kg) | 350 | 450 | 600 |
| power(kw) | 2.2 | 3.0 | 3.0 |
